Adaptor Prima Smooth to ICS

Adaptor Prima Smooth to ICS

This item is used to convert from Prima Smooth to ICS25.

  • 316L Grade Stainless Steel
  • Corrosion tested
  • Lightweight
  • Precision engineered jointing system
  • Available in matt black or steel finish
  • Can be painted
  • Range 125, 150, 180, 200
SKU: Adaptor to ICS25 0.6mm - Prima Smooth Categories: , , , Tags: , , , ,

Available Options:

Description

Prima Smooth is a high quality 316L grade stainless steel single wall flue system available with two wall thickness options of 0.6mm and 1mm.

There are two possible applications:

  1. Connecting flue pipe – Prima Smooth has been tested and approved for use as connecting flue pipe between an appliance and a system chimney.
  2. Chimney liner – Prima Smooth has been tested and approved for use as an alternative to a flexible stainless steel liner for re-lining an existing chimney.

Prima Smooth is a lightweight precision engineered product, designed for use on atmospheric wood burning and multi-fuel appliances with continuous operating temperatures of up to 600ยฐC. The joints in the pipe are designed to give a smooth visual appearance and Prima Smooth is available in two surface finishes:

  • Matt 316L grade stainless steel.
  • Matt black painted 316L grade stainless steel using a special high temperature resistant paint.
Technical details
Application Connection pipe/renovation pipe
Aggregation Non-condensing
Busy Under pressure
Maximum overpressure 0 Pa
Operating temperature 600ยฐC
Maximum allowed temperature 600ยฐC
Material AISI 316L/EN 1.4404
Wall thickness 0.6mm
Fuel wood/pellets normal (wood)/multifuel

For stove and chimney installers – whenever you register an installation with our easy to use, online guarantee registration portal, you will now accrue points based on the number of installations. So click here to start and register your installations, taking full advantage of our Lifetime Guarantee on Flex and ICID, as well as guarantees on all our other ranges, and to start earning points ๐Ÿ™‚

ICS brochure

ICS installation instructions

Click here to view Certificates and Declarations of Performance

Schiedel is the first European chimney manufacturer to have performed the tests according to this latest fire resistance standard for chimneys. European standard BS EN 1366-13:2019 โ€œFire resistance tests for service installations, Part 13: Chimneysโ€ and has reached EI 120 classification for our Double Wall Insulated System Chimney ICS in a closed scenario (type A) for both vertical and horizontal set-ups.

ICS is CE Certified to EN1856-1 TรœV 0036 CPR 9195 001 with designations
ICS is CE Certified to EN1856-2 TรœV 0036 CPR 9195 041 with designations

System Chimney EN1856-1

T450 N1 W V2 L50050 G60
T450 N1 D V3 L50050 G60
60mm Distance to combustibles in a combustible shaft*

T450 N1 W V2 L50050 G50
T450 N1 D V3 L50050 G50
50mm Distance to combustibles in a non combustible shaft or in free air*

T200 P1 W V2 L50050 O00
Zero distance to combustibles*

Connecting Flue Pipe EN1856-2

T450 N1 D V2 L50050 G100 M

  • Manufactured under a Quality Management Scheme approved to BS EN ISO 9001
  • 4 Hour Fire Rating to BS476 Part 20
  • Certified for corrosion resistance on gas, oil and solid fuel by Gastec, MPA and TรœV
  • HETAS listed for use on solid fuel applications.

Prima Smooth brochure

Prima Smooth installation instructions

Click here to view Certificates and Declarations of Performance

Prima Plus is CE Certified for the following high temperature applications

Connecting Flue Pipe
EN1856-2 TรœV 0036 CPR 9195 029
T600 N1 W V2 L50060 GXX NM T600 N1 W V2 L50100 GXX NM
(XX = 3 x ร˜ Int. of Pipe)

Chimney Liner
EN1856-2 TรœV 0036 CPR 9195 033
T600 N1 D V2 L50060 G
T600 N1 D V2 L50100 G

The Prima Smooth range is manufactured under the strict requirements of BS EN ISO 9001 Quality management scheme. Prima Smooth has corrosion certification from TรœV. Prima Smooth is listed by HETAS as a product suitable for solid fuel.
