Debris Plate – Flexible Liners

Debris Plate – Flexible Liners

Features and Benefits

Pre-cut and centred spigot hole → Seals off chimney base

Tight spigot → Holds component in place

SKU: Debris Plate - Flexible Liners Categories: , Tags: , , ,

Available Options:

Description

TecnoFlex Plus is a twin skin flexible chimney liner designed for gas, oil and multi-fuel, where the maximum flue gas temperature does not exceed 600°C. Diameter range 80 – 300mm. Flex Liners come with a Lifetime Guarantee*

Flexible Flue Twin Wall Liner

  • Corrugated outer skin for high crush resistance.
  • Extra smooth inner skin allows for easy drain down of condensates, less opportunity for soot to collect in the joint area and ease of sweeping.
  • Engineered joint design gives extra strength and flexibility.
  • Inner skin remains smooth and protective even after the rigours of installation.
  • Now with Lifetime*Guarantee.

Triplelock Plus is a single wall stainless steel flexible flue liner designed for atmospheric gas and kerosene appliances where the flue gas temperature does not exceed 260°C. Diameter range Triplelock plus 100 – 200mm.

Flexible Flue Single Wall Liner

  • Made from corrosion-resistant 316L stainless steel.
    Leak resistant construction due to dovetail folded seam.
  • Deep corrugations for high crush resistance and better flexibility when installing.
  • Strong seam construction resists the rigours of pulling the liner into place during construction.

Reviews

There are no reviews yet.

Only logged in customers who have purchased this product may leave a review.

Technical characteristics
Application Flue system/connecting flue/renovation
Operating mode Dry/wet
Pressure Negative/positive pressure
Max. working pressure 200 Pa
Operating temperature 200°C positive pressure
600°C negative pressure
Max. temperature allowed 1000°C (max 30 min)
material AISI 316L/EN 1.4404
AISI 904L/EN 1.4539
thickness 0.1 mm
Fuel type Oil/Gas/Wood/Pellets Normal (Wood)

TecnoFlex Plus is CE Certified to BS EN1856-2 TÜV 0036 CPR 9195 035 with designations:

High Temperature Applications
T600 N1 W V2 L50012 G
T600 N1 W V2 L70012 G

Low Temperature Applications
T200 P1 W V2 L50012 O
T200 P1 W V2 L70012 O

Triplelock Plus is CE Certified to BS EN1856-2 TÜV 0036 CPR 9195 043 with designations:

Applications
T300 N1 W V2 L50010 O
