UED starter adaptor

UED starter adaptor

The Metaloterm UE system is a modular twin wall flue system, made of stainless steel with an air gap insulation and sealing ring.

Metaloterm UE is suitable for low temperatures, condensing and non- condensing applications with flue gasses in positive or negative pressure. The system is suited for a wide range of applications such as condensing heaters and boilers, gas-fired stoves and ventilation systems.

Applications

  • Gas fired stoves
  • Oil fired stoves
  • Industrial ventilation systems
  • Air inlet or ventilation system
  • Condensing heaters and boilers
  • Atmospheric gas-fired boilers

Advantages

  • Universal applicable flue-system
  • Compatible with Metaloterm ME, Metaloterm MF
  • Pressure-tight up to 5000 Pa
  • Inner- and outer wall from high quality stainless steel
  • Stress free thermal expansion
  • Extremely low heat mass maintains draught and allows longer runs of installed flue
SKU: UED starter adaptor Categories: ,

Available Options:

Description

The Metaloterm® UE system is a modular twin wall flue system, made of stainless steel with an air gap insulation and sealing ring. Metaloterm® UE is suitable for low temperatures, condensing and non- condensing applications with flue gasses in positive or negative pressure. The system is suited for a wide range of applications such as condensing heaters and boilers, gas-fired stoves and ventilation systems.

CE approved | EN 1856-1:

T200 P1/H1 W V2 L50040 O25
T250 N1 W V2 L50040 O25
T400 N1 W V2 L50040 O130
T400 N1 D V3 L50040 G130

CE approved | EN 1856-2

T200 P1/H1 W V2 L50040 O50 M
T400 N1 W V2 L50040 O200 M
T400 N1 D V3 L50040 G200 M
